Replaceable 301-5.0 Blue PCB Screw Terminals
Buy Replaceable 301-5.0 Blue PCB Screw Terminals made in China. ZHDZWHR® is Replaceable 301-5.0 Blue PCB Screw Terminals manufacturer and supplier in China.
Send Inquiry
Product Description
Wholesale Newest Replaceable 301-5.0 Blue PCB Screw Terminals made in China. ZHDZWHR® is Replaceable 301-5.0 Blue PCB Screw Terminals manufacturer and supplier in China. ZHONGHENG Electronics, is a PCB screw terminal manufacturer from China, PCB screw terminal, current: 16A, nominal voltage: 250V, nominal cross section: 1.5 mm2, needle distance: 5.0 mm, connection: Screw connection with wire protection device, color: Blue, contact surface: tin
ZH301-500 Blue PCB Screw Terminals Parameter
| Pitch：500MM | ||
| Part | Material | Plated |
| Frame: | PA66 UL94V-0 | － |
| Contact: | Brass | Tin |
| Screw: | M2.5Steel | Ni |
| Wireprotector: | Stainless Steel | － |
| Electrical | ||
| Voltage: | 250V | |
| Current: | 15A | |
| Wire size: | 14-22AWG | |
| Poles: | 2-30P | |
| Insulation Reslistance: | 5000MΩ/1000V | |
| Withstand Voltage: | AC2000V/1Min | |
| Mechanical | ||
| Acceptable Temperation: | -33℃~+120℃ | |
| Max Soldering: | +250℃,5Sec | |
| Strip Length: | 5.0-6.0mm | |
Hot Tags: Replaceable 301-5.0 Blue PCB Screw Terminals, China, Manufacturers, Factory, Suppliers, Made in china, Quotation, Cheap, In stock, Free Sample
